galvanized steel pipe      10#-45#, Q195-Q345

  • galvanized steel pipe
  • galvanized steel pipe
  • galvanized steel pipe
  • galvanized steel pipe
Item Code:10#-45#, Q195-Q345 Features:Galvanized steel pipe 1.Outer diameter of steel pipe:20-165mm 2.thickness:1.3-4.5mm Both end screwed,with one socket and cap
  • Description
Galvanized steel pipe
1) Outer diameter of he galvaized steel pipe: 20-165mm
2) Wall thickness of the galvanized steel pipe: 1.3-4.5mm
3) Spec.: Q195, Q215, Q235, Q345
4) Standards: ASTM-A53A, BS1387-1985, GB/T3091-2001
5) Wall thickness: 1.4- 4.5mm
Both end screwed, with one socket, and protection on the other side, with red or blue belt
6Packing:
A) Hexagon bundles
B) Steel strapped
C) Oiled, varnished or stenciled



Specification
Outer diameter
(mm)
Thickness
(mm)
Galvanized steel pipe
1/2
20-21.3
1.3-2.2
3/4
25-26.8
1.3-2.2
1
31.5-33.5
1.4-2.2
1 1/4
41-42.3
1.5-2.2
1 1/2
46.5-48
1.7-2.2
2
58.5-60
1.7-2.2


Specification
Outer diameter
(mm)
Thickness
(mm)
Hot-dip galvanized steel

pipe
1/2
20-21.3
2.5-2.75
3/4
25-26.8
2.5-2.75
1
31.5-33.5
2.5-3.75
1 1/4
41-42.3
2.5-3.75
1 1/2
46.5-48
2.5-3.5
2
58.5-60
2.5-3.5
2 1/2
74.5-75.5
2.0-3.5
3
87-88.5
2.3-4.0
4
113-114
2.5-4.0
5
139-140
2.75-4.5
6
165
2.75-4.5
